Product features
Special Features
High speed : It can cut 60 - 120 pcs per minute. (50mm long)
Accuracy : Cut-length is accurate owing to a stepping motor.
Cutting type : Cutting is neat due to using a cold cutter which is durable because they are made of high-speed steel.
Automatic operation : It works automatically only by setting length and quality.
Automatic stopper : It stops automatically if materials run out during operation.
Memory : Set-length, set-q’ty & set-speed are not erased even if power off & on.
To be apply to
Belt loop, soft tube, string, plastic zipper, elastic band, small webbing, etc.
Specifications
| Model | SF-120L |
|---|---|
| Cutting Length (mm) | 1-99999 |
| Max. Cutting Width (mm) | 105 |
| Cutting Speed (p/min) | 120 |
| Voltage (V) | 110 / 220 |
| Frequency (Hz) | 50 / 60 |
| Power (kW) | 0.22 |
| Package Size (L * W * H) - mm | 410 * 525 * 430 |
| Weight (kg) | 24/29 |
| Loading Rate Pic | 1 |
