Product features
Customary needle designations: DPX17, 135X85, 135X535.
Customary needle designations
DPX17, 135X85, 135X535
Further point designations
SET, RD
Needle form description
Straight needle with single groove and scarf
Technical sewing application
Double lock stitch
Specifications
| Needle system | 135X17 LITESPEED |
|---|---|
| Point style | R |
| Needle size | 100 Nm |
| Coating | Chromium |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Overall length | 43.5 mm |
| Shank length | 16 mm |
| Length butt to eye | 38.9 mm |
| Shank diameter | 2.0 mm |
Catalogue
Groz-Beckert does not publish a separate leaflet for the 135X17. Their catalogues cover the whole range and open in a new tab.
The file is published and updated by the manufacturer; it is not copied here, so nobody downloads an outdated version.
Data sheets, photos, videos and specifications: Groz-Beckert.
Tell us the operation you need to solve and we will reply with the right configuration and the lead time.
