W3600P series
Pegasus
W3664HP-33A
Mid-range
Oil barrier type, cylinder bed, interlock stitch machines
Product features
Smart cylinder bed machines that create various new values Fully-automatic ・5,000 sti/min
Seam
Attaching flat elastic *without a top cover thread
Attaching flat elastic
Labor-saving and optional devices
FT device
Fabric edge trimmer
RP device
Rear puller
UT device
Thread trimmer
Specifications
| Stitch length adjustment | Dial |
|---|---|
| Differential feed ratio adjustment | Lever that can be adjusted intermittently during sewing |
| Lubrication | Fully-automtic |
| Max. machine speed(sti/min) | 5,000 |
| No. of needles | 3 |
| No. of threads | 5 |
| Needle space(mm) | 5.6, 6.4 |
| Type of needle plate finger | BS, CS |
| Accessories | FT,RP |
Videos
Catalogue
The W3664HP-33A documents Pegasus publishes, on their own site. They open in a new tab.
And the catalogues Pegasus publishes for their whole range.
The file is published and updated by the manufacturer; it is not copied here, so nobody downloads an outdated version.
Data sheets, photos, videos and specifications: Pegasus.
