Product features
Belt type, for feed-off-the-arm machines on very thick fabric.
PF-UB/ EFV/AF Belt type puller for Extra Heavy Duty (Gauge Set: 9/64"x9/64" or 1/8"x1/8" )
Adaptable machine Model: U.S 3580 0 JUKI MS3580 PEGASUS FV2 YAMATO DT-30 KANSAI SX6803
* Not suitable on Puller device
Specifications
| ADAPTABLE MACHINE | FEED-OFF-ARM |
|---|---|
| DRIVEN WAY | UPPER ROLLER |
| TRANSMISSION TYPE | P-2 |
| MIN. DISTANCE BETWEEN ROLLER and NEEDLE | 32 mm |
| BELT TYPE ( *Regular) | 210XL17 |
| PULLER LENGTH | 0.3~4.5 mm |
| SEWING MAX. SPEED (Continuous/Intermittent) | 3000/4500 |
| POWER | AC 100~240V |
