Consew
Consew 277R-3
Heavy Duty, Narrow Cylinder Arm, Single Needle, Drop Feed, Needle Feed, Compound Feed, Alternating Presser Feet, Lockstitch Machine
Product features
1 / 8
Heavy Duty, Narrow Cylinder Arm, Single Needle, Drop Feed, Needle Feed, Compound Feed, Alternating Presser Feet, Lockstitch Machine
With: Centra-Lube Semi-Automatic Lubrication System, Horizontal Axis Rotary Hook, Reverse Feed.
Big Bobbin Available: Model 277RB.
Specifications
| Number of Needles | 1 (Single) |
|---|---|
| Feeding Mechanism | Walking Foot |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Max Speed | 2300 S.P.M. |
| Stitch Length | 4.2 S.P.I. (15/64" or 6mm) |
| Work Space | 10 5/32" x 4 11/32" (258mm x 110mm) |
| Needle | 135 x 17 |
| Bobbin | 17035 L |
| Weight | 179 lbs (81kg) |
| Needle Bar Stroke | 1 5/16" (33.2mm) |
| Presser Lift | Hand 5/16" (8mm) – Foot 1/2" (13mm) |
| Cylinder Diameter | 1 13/16" Dia. (46mm) |
Catalogue
The Consew 277R-3 documents Consew publishes, on their own site. They open in a new tab.
Open the catalogue (PDF)Open the instruction manual (PDF)Open the parts book (PDF)
And the catalogues Consew publishes for their whole range.
The file is published and updated by the manufacturer; it is not copied here, so nobody downloads an outdated version.
Product information, photographs and specifications: Consew. No prices or stock here: ask us and we will get back to you.
Tell us the operation you need to solve and we will reply with the right configuration and the lead time.
