Product features
1 / 8
Heavy Duty, High Speed, Two Needle, Lockstitch Machine, Drop Feed, Needle Feed and Alternating (Walking) Presser Feet
With: Centra-Lube Semi-Automatic Lubrication System, Large Vertical Axis Hooks and Bobbins, Reverse Feed, Safety Clutch
Applications
For sewing light to heavy-weight materials such as leather, vinyl, upholstery, synthetics, canvas, and various coated and laminated products.
Suitable for stitching products like auto, boat, and furniture upholstery, tarpaulins, covers, sails, tents, camping trailer covers, awnings, umbrellas, tops, bags, luggage, handbags, travelware accessories, sports and camping equipment, wearing apparel, outdoor clothing, canvas shoes, slippers, and orthopedic appliances.
Ideal for double needle seaming, binding, taping, and piping operations.
Features
Two-needle mechanism for parallel lines of stitches.
Compound feed, walking foot mechanism ensures even feeding of material.
Large hooks and bobbins for longer operation between bobbin changes.
Centra-Lube® semi-automatic lubrication system.
Automatic hook lubrication.
Oil-fed take-up.
Simple adjustment for raising and lowering the center foot to sew different thicknesses of material.
Safety clutch protects hooks from damage.
Various needle gauges available.
Synchronized puller available (add suffix -P).
Large hooks, bobbins, and reverse feed with long stitch (2 1/2 s.p.i.).
Specifications
| Number of Needles | 2 (Double) |
|---|---|
| Feeding Mechanism | Walking Foot |
| Workspace | Long Arm |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 2400 |
| Clearance Under Presser Foot | 9/16" (14mm) |
| Stitch Length | 2 1/2" s.p.i. (10mm) |
| Work Space | 25" (640mm) |
| Needle | 135 x 17 |
| Bobbin | Metal 15041, Pre-wound S or U |
| Bed Size | 7" x 28 1/4" (177mm x 718mm) |
| Stitch Type | 301 |
| Weight | 266 lbs |
| Needle Bar Stroke | 1 5/16" (33mm) |
| Available Needle Spacings | 1/8" (3.2mm) - 1 1/2" (38.1mm) |
| Standard Needle Spacing | 1/4" (6.4mm) |
| Hook | 15502 |
Videos
Catalogue
The Consew 339RBL-25 documents Consew publishes, on their own site. They open in a new tab.
Open the catalogue (PDF)Open the instruction manual (PDF)Open the parts book (PDF)
And the catalogues Consew publishes for their whole range.
The file is published and updated by the manufacturer; it is not copied here, so nobody downloads an outdated version.
Data sheets, photos, videos and specifications: Consew.
